Mouser Electronics, the authorized global distributor with the newest electronic components and industrial automation products, is now shipping the new ultra-compact Type 2LL Wi-Fi 6/Bluetooth/802.15.4 module from Murata. The Type 2LL module is a small, high-performance solution designed to enhance connectivity and efficiency in various IoT, handheld wireless, and gateway applications.
The Murata Type 2LL module, available from Mouser, is based on the IW610G tri-radio system-on-chip (SoC) from NXP Semiconductors, which integrates Wi-Fi 6, Bluetooth Low Energy (BLE) 5.4, and 802.15.4 radios into a compact solution, providing robust wireless communication capabilities.
The Wi-Fi 6 subsystem offers improved network efficiency, reduced latency, and an extended range, while the Bluetooth LE radio supports high-speed data rates and long-range communication. Additionally, the 802.15.4 radio offers PHY data rates of up to 114.7 Mbps on Wi-Fi and 2 Mbps on BLE. The Wi-Fi supports SDIO v3.0 DDR50 interfaces, while the Bluetooth section facilitates a high-speed 4-wire UART interface and PCM for audio data.
The Type 2LL module is packaged in an impressively small, shielded form factor (8.8 × 7.7 × 1.3 mm3) that facilitates integration into size and power-sensitive applications. The Type 2LL employs highly rich, enhanced collaborative coexistence hardware mechanisms and algorithms, enabling optimized collaboration among Wi-Fi, Bluetooth, and 802.15.4 for maximum performance. In IEEE 802.11ax mode, the Wi-Fi operation assists rates of MCS0-MCS9 (up to 256QAM) in 20MHz channels for data rates.
As a global authorised distributor, Mouser offers the world’s widest selection of the newest semiconductors and electronic components — in stock and ready to ship. Mouser’s customers can expect 100% certified, genuine products that are fully traceable from each of its manufacturer partners. To help speed up the design process for customers, Mouser’s website hosts an extensive library of technical resources, including a Technical Resource Centre, along with product data sheets, supplier-specific reference designs, application notes, technical design information, engineering tools and other helpful information.
