IBASE Technology, a leading provider of industrial panel PC and embedded computing solutions, is pleased to announce the IPPC-121, a fanless industrial panel PC engineered for high-reliability deployment across demanding automation and control environments. Powered by a range of Intel processors including the Core 3 N355, Core i3 N305, Atom N97, and Atom X7835RE, the system provides scalable performance for various workloads, from HMI to edge computing in harsh industrial conditions.
The IPPC-121 features a 12.1-inch projected capacitive touchscreen with 1024×768 resolution and 500 cd/m² brightness, enclosed in a rugged chassis with IP65-rated front panel. The design supports both 6mm T-slot and V-slot linear rail, allowing flexible mechanical integration. All configurations are completely fanless and support operating temperature ranges from -20°C to 45°C (N355/N305/N97), and up to 60°C for the X7835RE variant.
In terms of connectivity, the IPPC-121 excels with rich I/O: 2x COM ports (expandable to 6 with power COM), 4x USB 2.0, 2x USB 3.2, USB Type-C with 60W PD, 2x 2.5GbE LAN ports, HDMI, and a 4x DI / 4x DO digital interface. Internally, it offers three M.2 slots (2280 M+B key, 2230 E-key, and 3052 B-key) to support WiFi, Bluetooth, 4G/5G modules, and a Nano SIM slot. These features ensure the system is ready for industrial IoT and wireless edge deployments.
With support for TPM 2.0 hardware security, wide 9V–36V DC input, and OS compatibility across Windows 10/11 and Linux Kernel 4+, the IPPC-121 provides a secure, rugged, and scalable platform. From factory floor terminals to smart energy systems, this product represents IBASE’s commitment to industrial-grade reliability, flexibility, and high-performance embedded design.
IPPC-121 FEATURES:
- Intel Atom x7000E Series / N-series / Core 3 N355 / Core i3 N305 Processors
- Compliance with 6mm T and V-Slot Linear Rail
- 12.1″ flat LCD panel with projected capacitive touchscreen
- IP65 Front Panel Waterproof Design
- Rich I/O supports 2x COM, 4x Optional Power COM, 4x DI, 4x DO, USB Type-C with PD 60W Alternate mode and 6x USB (2x USB 3.2 + 4x USB 2.0)
- Supports M.2 sockets for WiFi / BT and 4G/5G communication with a Nano SIM slot
- Supports hardware TPM 2.0 security
- Wide Range Power Input +9V ~ 36V DC-in
